Transformer core grounding current tester,Iron core grounding current detector,HB-BT

Transformer core grounding current tester Iron core grounding current detector AC leakage current meter AC Leakage clamp current meter Transformer core grounding current monitor HuaBao brand transformer core grounding current tester is an in
订购热线:18653225978
  • 产品详细
Transformer core grounding current tester
Iron core grounding current detector
AC leakage current meter
AC Leakage clamp current meter
Transformer core grounding current monitor
HuaBao brand transformer core grounding current tester is an intelligent portable anti-interference large capacity transformer core grounding current tester developed and produced by Huabao electric and Huahao power. It is widely used in substations, power plants, electric power, communication, meteorology, railways, oil fields, construction, measurement, scientific research and teaching units, industrial and mining enterprises, etc Leakage current test of iron core and clamp of electric equipment such as reactor.
HB-BT,186+5322+5978,QQ1123+134968
1、 Functional features
1. Clamp current transformer is adopted to facilitate on-site operation;
2. Strong anti-interference ability to ensure accurate and reliable data;
3. Cooperate with high-speed microprocessor to display measurement data and waveform in real time;
4. FFT transform, digital filter and other algorithms are used for data processing;
5. It has leakage current over limit alarm function, and the alarm current can be set;
6. It adopts 3.5-inch 320×240 true color LCD screen and windows menu operation tips;
7. Built in large capacity nonvolatile memory, which can store 100 groups of measurement data;
8. Built in high-precision real-time clock function: date and time calibration;
9. Built in 1600ma rechargeable lithium battery, standby time 2-3 hours, convenient for on-site use.
2、 Technical parameters
1. Measuring range: current: 0-10A
2. Frequency: 50±1Hz
3. Resolution 0.01
4. Measurement accuracy ± 1% (reading + 2 words)
5. Overall dimension 203mm×112mm×38mm
6. Instrument weight: 0.5kg
Supply: transformer iron core grounding current tester iron core grounding current tester AC leakage current meter AC Leakage clamp current meter transformer iron core grounding current monitor
Solemnly declare: Qingdao Huabao Electric has no branch or distribution office, and no relatives do this business. Those similar or similar units or individuals have nothing to do with our company. Please identify the brand of Huabao (HB) when purchasing and contact our company directly to prevent counterfeiting. For details, please consult the hotline 186 + 5322 + 5978.

变压器铁芯接地电流测试仪 铁芯接地电流检测仪 交流漏电电流表 交流漏电钳流表 变压器铁芯接地电流监测仪
华宝牌变压器铁芯接地电流测试仪是华宝电气与华豪电力研制生产的智能型便携式抗干扰大容量变压器铁芯接地电流测试仪器,广泛适用于变电站、发电厂、电力、通信、气象、铁路、油田、建筑、计量、科研教学单位、工矿企业等作为变压器、电抗器等电气设备的铁芯与夹件的泄漏电流测试。
HB-BT,手微186+5322+5978,QQ1123+134968
一、功能特点
1、采用钳形电流互感器,方便现场操作;
2、抗干扰能力极强,确保数据准确可靠;
3、配合高速微处理器,实时显示测量数据及波形;
4、运用FFT变换、数字滤波等算法进行数据处理;
5、具有泄漏电流超限报警功能,报警电流可设置;
6、采用3.5英寸320*240真彩液晶显示屏,Windows菜单操作提示;
7、内置大容量非易失性存储器,可存储100组测量数据;
8、内置高精度实时时钟功能:可进行日期及时间校准;
9、内置1600mA可充电锂电池,待机时间2~3小时,方便现场使用。
二、技术参数
1、测量范围 电流:0~10A
2、频率:50±1Hz
3、分 辨 率   0.01
4、测量精度   ±1%(读数+2字)
5、外形尺寸   203mm×112mm×38mm
6、仪器重量   0.5kg
供应:变压器铁芯接地电流测试仪 铁芯接地电流检测仪 交流漏电电流表 交流漏电钳流表 变压器铁芯接地电流监测仪

郑重声明:青岛华宝电气没有分公司或经销处,也没有啥亲戚干这行,那些相似或相近的单位或个人均与我公司无关,购买时请认准华宝(HB)品牌,直接与我公司联系,谨防假冒,具体可咨询热线186+5322+5978。
